Home » Products » Current Transformers » ESCT-TA16-10A/100mA

ESCT-TA16-10A/100mA


SKU: 115-03416-0010
8,24
  • Primary 10A
  • Divisible, maximum Ø16mm
  • RJ12 for EasyClick
Specifications
Downloads
Description
Returns Policy

Specifications

Product

Weight 0,250 kg
Primary current

10A

Secondary current

100mA

Accuracy class

0.5, 1

Certification

CE

Cable entry

16mmØ

Manufacturer

Eastron

Length

46,8mm

Width

36,1mm

Height

32,3mm

HS code

85043129

Country of origin

China

Downloads

Description

The ESCT-TA16-10A/100mA is a divisible current transformer which is easy to install and connect to RJ12 energy meters using an additional connection cable with RJ12 jack. Once connected, the ESCT-TA16-10A/100mA has a measurement class of 0.5 and 1, a primary current value of 10A and a secondary current value of 100mA. The maximum diameter of the cable entry is Ø16mm.
